رله محافظ موتور ای بی بی ABB کد فنی 1SVR730700R2200

CM-MSS.23S

General Information

• Extended Product Type:

  CM-MSS.23S

• Product ID:

  1SVR730700R2200

• EAN:

  4013614496691

• Catalog Description:

  CM-MSS.23S Therm. motor protec. relay 2c/o, 110-130VAC/220-240VAC

• Long Description:

  The CM-MSS.23S belongs to the CM-MSS thermistor motor protection relay range. It operates with a rated control supply voltage of 110-130 V AC and 220-240 V AC and has a 2 c/o (SPDT) output with contacts rated at 250 V / 4 A. It features one sensor circuit to monitor PTC temperature sensors and works according to the closed-circuit principle. The relay can be reset automatically, manually or remotely after the failure has been removed. A sealable transparent cover for protection against unauthorized changes is available as accessory. The device offers screw connection technology with double-chamber cage connection terminals.
